DorGO 800 Garage Door Motor Kit
Price range: R3 593,75 through R5 387,75 Incl. VAT
Compact and cost-effective sectional garage door motor with soft start/stop, obstacle sensing, LED lighting and standard battery backup.
Features
- Easy installation with quick step-by-step programming
- Soft start and soft stop
- Obstacle sensing feature
- Accurate limits
- LED lighting
- Chain rail system (2 length options)
- Battery backup (2 options)
- Quiet operation
- 2 year product warranty
- Includes 2 remotes with battery (27A 12V)
Specifications
| Supply voltage | 230V AC – 50Hz |
|---|---|
| Control voltage | 24VDC |
| Motor power | 120W |
| Drive | 800 N |
| IP rating | IP20 |
| Speed | 140 mm/sec approx. |
| Lift capacity | Doors up to 12 m² and 100 kg |
| Temperature range | -30°C to +65°C |
| Protection | Internal use |
| Weight | 4.9 kg |
| Rail length | 3.3 m – max travel 2.5 m |
| Remote controls | 433 MHz rolling code, range ±25 m |
| Battery backup | 1.2Ah standard, 3.5Ah optional |
| Chain rails | 3.0 m = 2.1 m max opening; 3.3 m = 2.4 m max opening; 3.9 m = 3.0 m max opening |
(The Company reserves the right to amend product specifications and information without notice.)
Downloadable Resources
Product details
Compact and cost-effective sectional garage door motor with soft start/stop, obstacle sensing, LED lighting and standard battery backup.
Features
- Easy installation with quick step-by-step programming
- Soft start and soft stop
- Obstacle sensing feature
- Accurate limits
- LED lighting
- Chain rail system (2 length options)
- Battery backup (2 options)
- Quiet operation
- 2 year product warranty
- Includes 2 remotes with battery (27A 12V)
Specifications
| Supply voltage | 230V AC – 50Hz |
|---|---|
| Control voltage | 24VDC |
| Motor power | 120W |
| Drive | 800 N |
| IP rating | IP20 |
| Speed | 140 mm/sec approx. |
| Lift capacity | Doors up to 12 m² and 100 kg |
| Temperature range | -30°C to +65°C |
| Protection | Internal use |
| Weight | 4.9 kg |
| Rail length | 3.3 m – max travel 2.5 m |
| Remote controls | 433 MHz rolling code, range ±25 m |
| Battery backup | 1.2Ah standard, 3.5Ah optional |
| Chain rails | 3.0 m = 2.1 m max opening; 3.3 m = 2.4 m max opening; 3.9 m = 3.0 m max opening |
(The Company reserves the right to amend product specifications and information without notice.)
Downloadable Resources
Additional information
| Weight | 4,9 kg |
|---|---|
| Opening Height | 2.4m – 3.3m Long Rail, 3.9m Long Rail |
| Battery | 1.2AH Battery, 3.5AH Battery |
